This Household solar power system is a home solar power system that is worth buying, and it can continuously power your home appliances for up to 190 hours. Support household appliances within 300W, such as TVs, electric fans, and light bulbs.
Item No.:
12V200WProduct Name:
Off grid solar power systemBattery Capacity:
80AHVoltage:
12VOEM/ODM:
YesWarranty:
25YearsCertificate:
RoHS, CE, PatentType:
Portable solar system200W DC12V solar power system for homes
This portable household 12V solar power system has load protection, 2 solar panels, with a lifespan of up to 25 years, and can power electrical appliances within 300W, such as a 150W TV set for 6 hours; a 50W fan, power supply for 19 hours; 5W bulb power supply can reach 190 hours. It is definitely a cost-effective home solar power system, outdoor solar power system, easy to carry, it can meet the basic power supply even when the family is camping or performing.
200W Solar Power System Specifications:
Host *1
Input voltage
DC12V
Maximum charging current
15A
Maximum discharge current
25A
USB
1A/5V
LED indicator
Switch, battery
AC220V output interface
2PCS
DC12V output interface
8PCS
Charging control method
PWM Controller
Temperature difference supplement
-4MV/0°/2V
Load protection
Overcharge, overdischarge, overload, short circuit
Size
345*210*245mm
Weight
4.03KG
Built-in inverter
300W
Solar panel *2
Maximum output power（Pm）
100W
Optimal power voltage (Vmp)
17.6V
Optimal power current (Imp)
5.71A
Open circuit voltage (Voc)
21V
Short circuit current (Isc)
6.4A
Size
1200*540*30mm
Weight
7KG
Conversion efficiency
18%
Power deviation
3%
Cell
Monocrystalline silicon
Service life
More than 25 years
Battery *1
Battery Type
Valve-controlled maintenance-free gel battery
Voltage
12V
Capacity
80AH
Size
324*200*230mm
Weight
24.5KG
Accessories
LED lights *2
12V/3W
LED light wire *2
5M
Data line *1
* All accessories are equipped according to the ordered products and user needs.
* Your requirements can be customized.
Advantages of solar power system:
Compared with commonly used thermal power generation systems, the advantages of solar power system are mainly reflected in:
1. No risk of fatigue
2. Safe and reliable, no pollution discharge, clean and tidy (no pollution)
3. It is not restricted by the geographical location of resources, and can take advantage of the geographical location and the roof of the building
4. There is no need to consume fuel, and no need to erect transmission lines to generate electricity
5. High energy quality
6. Short construction period and short energy acquisition time
7. Save money
Applications:
We focus solar system solution for many years, as a professional solar power system manufacturer and supplier, we value user experience, product quality, and customer satisfaction is our pursuit.
If you want to wholesale or customize solar products, you can rest assured to contact us, the price is favorable, and the quality is guaranteed. Contact today!
